PR224/E

Views:
100
0765 259 545

Applications
Basic Weighing, Parts Counting, Percent Weighing
Display
Backlit Liquid Crystal Display (LCD
Operation

AC adapter (included)
Communication
RS232 (one port included)

Construction

ABS top housing, removable stainless steel pan, removable glass draftshield with sliding top door, integrated weigh-below-hook, security bracket, calibration lock

Design Features

User-selectable environmental filters and brightness settings, auto-tare, auto-dim, user-selectable span calibration points, software lockout and reset menu, userselectable communication settings and data print options, user-definable project and user IDs, software overload/underload indicator, stability indicator

Ứng dụng:

Products Information
Comment

Specifications

Maximum Capacity	220 g
Readability	0.1 mg
Pan Size	3.5 in (90 mm)
Internal Calibration	Not Applicable
Draftshield	Included
Auto Door	Not Applicable
Auxiliary Display Model	Available as an Accessory
Battery Life	Not Applicable
Built-in Ionizer	No
Communication	RS232
Dimensions	12.5 in x 11.9 in x 7.9 in (317 mm x 303 mm x 201 mm) (LxHxW)
Display	LCD with backlight
In-Use Cover	No
Legal for Trade	No
Linearity ±	0.0002 g
Minimum Weight (USP, 0.1%, typical)	200 mg
Net Weight	10 lb (4.5 kg)
Pan Construction	Stainless Steel
Power	AC Adapter (Included)
Repeatability, typical	0.0001 g
Stabilization Time	3 s
Tare Range	To capacity by subtraction
Units of Measurement	Milligram; Pennyweight; Ounce Troy; Newton; Taiwan Tael; Gram; Grain; Ounce; Carat; Custom
Working Environment	operability guaranteed between 41°F and 104°F; 50°F – 86°F, 80%RH, non-condensing (operability guaranteed between 5°C and 40°C; 10°C – 30°C, 80%RH, non-condensing)
