Powder Characteristics Tester

HMK-22 Fisher Sub-Sieve Sizer/Average Particle Size Analyzer (FSSS fisher sub sieve sizer) (P/N 20198) works on fisher sub sieve sizer theory and method i.e. air permeability method to fast determine average particle size i.e. fisher number particle size of powders. It complete meets international standard about fisher sub sieve sizer ISO 10070 Metallic powders Determination of envelope-specific surface area from the measurements of the permeability to air of a powder bed under steady-state flow conditions and ASTM B 330 Standard Test Method for Fisher Number of Metal Powders and Related Compounds. It has become the best successor of discontinued Fisher Model 95 sub sieve sizer. HMKTest supplies fisher sub sieve sizer parts including fisher sub sieve sizer model 95 parts. HMK-22 fisher sub sieve sizer particle size analyzer represents US quality fisher sub sieve sizer for sale.

AIR JET SIEVES AIR-200 Air jet sieve is a particle size analyzing machine that works in advanced air jet sieve principle for sieve analysis. AIR-200 is a micron air jet sieve (measuring 10 µm-~ 4 mm) equipped with a patented rotating slotted nozzle. AIR-200 air jet sieve is a particle analysis equipment uses a vacuum to generate negative pressure in order to effectively measure particle size. The diameter of the sieving tank is 200/203 mm designed for 8 inch air jet test sieve both 1″ or 2″ high sieve available, stainless steel frame and mesh. It suits powdered materials that require particular dispersion and dis-agglomeration very much. AIR-200 air jet sieve has same performance to ALPINE air jet sieve and HOSOKAWA air jet sieve analyzer.HMK-200 is specially designed for pharmaceutical applications, HMKTest develop AIR-200 Standard air jet sieve and HMK-200 Inteliggent air jet sieve . All air jet sieve screens is ASTM E11 Compliance grade.

Electromagnetic Vibratory Sieve Shaker SIEVEA 502 Electromagnetic Vibratory Sieve Shaker is designed and manufactured to meet higher requirements for sieving in the lab.The instrument is in fact a sieve shaker in the lab.It consists of sieve base, electromagnetic generator, sieve holder and standard test sieves.SIEVEA 502 uses electromagnetism as driving force, distribute the powder uniformly throughout the screen,and do three-dimensional oscillation at the same time.This particular vibratory method effectively prevents the blockage of sieve holes by near-sieve particles. So that the undersize particles can effectively passed the sieve. According to the particle size grade numbers the user can choose standard test sieve with different mesh size.The sieving instrument has higher work efficiency and less noise, and is widely used in medicine, food and chemical industry etc.

AS-300A Hall Flowmeter Model: AS-300A Manufacturer: HMK Test Origin: China AS-300A Hall Flowmeter (Funnel) /Hall Flow Meter (Funnel) determines both Hall Flow Rate and Apparent Density of free-flowing metallic powders as well as other fine powders in various particle size distributions with calibrated Hall Flowmeter funnel or Carney Funnel as well as most advanced Gustavsson Funnel.

TAP DENSITY TESTER LABULK 0335 Intelligent Tap Density Tester is used to measure tapped density or packed density of powders, as well as granulated or flaked materials by automatically standardized and repeatable procedures. LABULK 0335 tap density equipment consists of 7 inch broad LCD panel, micro controller, printer, balance, glass cylinder and holder as well as sound acoustic cabinet. LABULK 0335 tapped density apparatus features easy operation, compact in size, light in weight, tapping height and speed controllable, tap density results savable and printable, it also output flowability data automatically such as Hausner Ratio and Compressibility Index(Carr compressibility). It conforms to all relevant international standards and being widely used in metal, pharma, food, chemical etc industries. LABULK 0335 has become the most price performance ratio tap density tester for sale. LABULK 0335 conforms to all international standards such as USP 616, ASTM B527 ISO 787/11 etc.

AIR-200 Economic Air Jet Sieve (P/N 51098A) meets user’s basic requirement on sieving powders by air jet. Put sample into the instrument and start negative pressure and timer until sieving finishes. It now becomes AIR-200 Standard Air Jet Sieve features auto calculation and print.

LASER PARTICLE SIZE ANALYZER AS-2011 Laser Particle Size Analyzer works with principle of Mie Scattering to precisely determine the particle size distribution from 0.1 to 500 micrometer. This equipment has a few advantages all its own. Robust laser diode and innovative photocells optimize the precision of static light scattering and give AS-2011 a longer operational lifetime. Patented optical bench uproots light path deviation, one of the major technical problems in the industry of particle size analysis. User-friendly program and advanced algorism bring accuracy and repeatability qualification to International Norm ISO13320-1 Particle Size Analysis – Laser Diffraction Methods. AS-2011 has become the most reliable and cost-effective LPSA and being widely used in Particle Characterization.

Intelligent Tapped Density Tester Model: LABULK 0335 Manufacturer: HMKTest Origin: China LABULK 0335 Intelligent Tap Density Tester is used to measure tapped density or packed density of powders, as well as granulated or flaked materials by automatically standardized and repeatable procedures. LABULK 0335 tap density equipment consists of 7 inch broad LCD panel, micro controller, printer, balance, glass cylinder and holder as well as sound acoustic cabinet. LABULK 0335 tapped density apparatus features easy operation, compact in size, light in weight, tapping height and speed controllable, tap density results savable and printable, it also output flowability data automatically such as Hausner Ratio and Compressibility Index(Carr compressibility). It conforms to all relevant international standards and being widely used in metal, pharma, food, chemical etc industries. LABULK 0335 has become the most price performance ratio tap density tester for sale. LABULK 0335 conforms to all international standards such as USP 616, ASTM B527 ISO 787/11 etc.
