Moisture Meter PCE-CMM 5

Test stand STAND-PCE-DDx10 Order no.: STAND-PCE-DDx10 Model: PCE-DDx10

Particle Counter PCE-PCO 1 Model: PCE-PCO 1 Manufacturer: PCE - UK Contact for quote: 0765 259 545 PCE-PCO 1 Particle Counter Handheld laser dust measuring device for monitoring clean room particulate concentrations, indoor air quality and exposure to dust This is a laser particle counter, or dust measuring device, for measuring the concentration of particles in the air. The dust measuring device is ideal for monitoring clean rooms, indoor air quality, exposure to exhaust, tobacco or cigarette smoke and other harmful air pollutants, and levels of airborne dust. Cigarette smoke particles mainly are distributed in the size range from 0.1 to 1.0 micron. A variety of materials are explosible in dust form. Some examples include: food (e.g., candy, sugar, spice, starch, flour and feed), grain, tobacco, plastics, wood, paper, pulp, rubber, pesticides, pharmaceuticals, dyes, coal and metals (e.g., aluminum, chromium, iron, magnesium and zinc). These materials are used in agriculture, chemical manufacturing, pharmaceutical production, furniture, textiles, fossil fuel power generation, recycling operations, metal working and processing (including additive manufacturing and 3D printing) and many other industries and processes. In addition to being a combustion hazard, certain kinds of dust can be a health hazard. Exposure (such as skin contact, eye contact and inhalation) can be linked to sneezing, a stuffy or runny nose, itchy or red eyes, headaches, fatigue, fever, cough, shortness of breath, dermatitis, asthma, bronchitis, pneumonia (e.g., Legionnaires’ disease and hypersensitivity pneumonitis) and cancer.

Soil Moisture Meter Model: PCE-SMM 1 Manufacturer: PCE -UK Origin: China The amount of the water content in the soil plays an important role in many sectors in the agriculture, horticulture and environmental protection. It is so, because the moisture of the soil allows, among other things, making conclusions about characteristics, fertility and water storage capacity. The PCE Instruments Soil Moisture Meter with a 250-millimetre-long probe has been specifically designed to quickly, easily and accurately measure the moisture content of soils. The user-friendly soil moisture meter reliably displays the water content in soils in the range of 0 to 50 percent with a resolution of 0.1 percent.The soil moisture meter PCE-SMM 1 for waterproof information. The application of the soil moisture meter is simple and effective. After the sensor with two-pole moisture electrode is plugged onto the housing, the probe can be fixed by screwing the ring tight. When the protective cap of the sensor head is removed, the soil moisture meter is ready for use. To determine the water content in the soil, the probe of the soil moisture meter should be placed at least ten centimetres deep into the soil. The results of the measurement are then presented quickly on the large and easy-to-read LC display of the soil moisture meter. The manufacturer has equipped the soil moisture meter with a convenient data recording function that stores minimum and maximum values of a measurement. The compact dimensions and the battery operation enable mobile use of the soil moisture meter while the stable and waterproof plastic housing protects the internal components even in harsh operating conditions. To ensure that the battery-operated soil moisture meter is always ready for use, the device always indicates timely when a battery change is necessary. The soil moisture meter can be used in the temperature range between 0 and 50 degrees Celsius and at a humidity level of up to 80 percent.

Color Meter PCE-CSM 1 Model: PCE-CSM 1 Manufacturer: PCE -UK Origin: China - The color meter PCE-CSM 1 was developed for quality control and offers a very high accuracy. When using the color meter, you can choose between different color spaces (CIE L*a*b*C*h, CIE L*a*b* and CIE XYZ). After a measurement with the color meter, the reading can be used as a reference value while other readings can be recorded as a sample and later be compared to the reference value easily. - In addition to the individual color space coordinates, the deviation between the reading is also displayed. When using the color meter, it is possible to store up to 100 reference values and up to 20,000 samples on the device. The measured data can also be transferred to a PC via the USB interface. A special PC software is included in the package.

Moisture Tester for Wood Model: PCE-PMI 1BT Manufacturer: PCE -UK Origin: China The moisture tester for wood has a measuring range of 0.0…. 100.0%. For a measurement, the ball head is positioned on the test object by the moisture meter. This guarantees a non-destructive measurement with the moisture meter. The moisture meter is therefore used, for example, for on-site inspections of buildings, wood and other surfaces. A connection can be established with the moisture tester for wood via the free app. As soon as a connection has been established, the current measured value is displayed by the moisture meter. The recorded data can be exported as .csv and .pdf after a measurement. This means that the data measured by the moisture meter can be processed further.

Moisture Tester for Wood Model: PCE-WP24 PCE - UK China - PCE-WP24 is a moisture tester or meter for wood used to perform noninvasive, nondestructive moisture measurements of wood, timber and other construction or building materials. An ideal tool for assessing everything from lumber to floors and more, this moisture meter uses electromagnetic waves that penetrate approximately 50 mm / 1.96 inches to 60 mm / 2.36 inches deep (depending on substrate) to return a mean-value moisture content percentage. - To measure, simply select either wood or building material (BUILD. MAT.) on the meter and place the meter's electrodes on the surface of the substrate. For accurate results, be sure to calibrate the instrument before each use according to the instructions outlined in the user manual.

Coating Thickness Meter Model: PCE-CT 25FN Manufacturer: PCE - UK Origin: China - The coating thickness meter is used for the quick and precise detection of layer thicknesses on metals. In comparison to many other coating thickness meters, this coating thickness meter does not have to differentiate between ferrous and non-ferrous metal. With the small and compact design of the coating thickness meter, one-hand operation is possible. Despite its small size, the coating thickness meter has a measuring range of 1500 µm and an accuracy of ± (3% + 1 µm). - The measured values displayed can be output in µm, mm and in mils on the coating thickness meter. In addition to measuring the layer thickness, the coating thickness meter can determine the smallest, the largest and also the mean value from a series of different measurements. The coating thickness meter also has an automatic switch-off function.

Moisture Meter Model: PCE-UX 3011Q Manufacturer: PCE -UK Our Moisture Meter is a special device for temperature-insensitive materials with a maximum drying temperature of up to 360 °C. It is ideal for applications in raw material extraction, production, processing, research and recycling, as well as especially for building materials such as cement, concrete and gravel and the chemical industry, including powders, granulates and pastes. With a maximum sample weight of 220 g and a high measuring resolution of 0.001 g, it enables precise moisture measurement. The operating principle is based on drying with simultaneous weighing, whereas the weight loss is continuously recorded and displayed as a percentage of the total mass. With a heater output of 375 W and an adjustable heating temperature of 105 °C to 360 °C, the Moisture Meter ensures quick, precise drying, even with challenging materials. Parameters such as % moisture, % dry matter, % moisture bd as well as g residual weight / kg and residual weight are available for the measurement evaluation, allowing the sample to be analysed in detail. An automatic power-off function stops the drying process automatically when a constant weight is reached. The automatic power-off can be controlled via three adjustable criteria: sampling start, sampling interval and weight loss per sampling interval, allowing flexible and precise control of the process. The Moisture Meter also has a timer that can be set from 1 to 180 minutes. The menu lock protects against accidental adjustment of the parameters and can be secured by a PIN whereas calibration mode (CAL) remains accessible. The balance also has a programme memory with up to 9 memory locations to store and quickly call up different drying profiles.

Moisture Meter PCE-UX 3011 Model: PCE UX 3011 Manufacturer: PCE -UK Our Moisture Meter is a precise device for determining moisture in liquid and solid materials. It is suitable for various applications in raw material extraction, production, processing, research and recycling. With a maximum sample weight of 220 g and a high measuring resolution of 0.001 g, the Moisture Meter enables precise moisture measurement. The balance works on the principle of drying with simultaneous weighing. During drying, the weight loss is continuously recorded and displayed as a percentage of the total mass. With a heater output of 250 W and an adjustable heating temperature of 40 °C to 180 °C, the Moisture Meter ensures quick and flexible drying of the samples. For measurement evaluation, the device offers various parameters such as % moisture, % dry matter, % moisture bd as well as g residual weight / kg and residual weight, which enable the sample to be analysed. The functions include an automatic power-off function that stops the drying process when a constant weight is reached. The automatic power-off can be set to three criteria: start of sampling, sampling interval and weight loss per sampling interval. This allows a high degree of flexibility in controlling the drying process. There is also a timer that can be set from 1 to 180 minutes. Our device is also equipped with a menu lock that prevents accidental adjustment of the parameters. The menu can be locked using a PIN whereas the CAL menu item remains available. The balance also has a programme memory with up to 9 memory locations to store and quickly call up different drying profiles. Data can be transferred to a PC via a software which must be purchased separately. All data can also be output via the serial RS-232 interface and USB. The Moisture Meter guarantees GLP-compliant documentation. The data is output via the Data Bridge software as the balance does not have a built-in printer. The Moisture Meter also has a 4-digit device ID for unique identification of the device, which enables precise allocation of the measurement data. The Moisture Meter is suitable for moisture determination in many branches of industry, such as food and beverages (e. g. coffee, flour), pet food, chemical industry, pharmaceutical industry, agriculture, dairy processing, meat processing, wood industry, textile processing, recycling and sewage treatment plants. The Moisture Meter provides reliable measurements for a wide range of temperature-insensitive materials.

Multi-function Air Moisture Meter Model: PCE-WM1 Manufacturer: PCE -UK Origin: China - PCE-WM1 is a multifunction air moisture meter used to determine relative humidity (% RH), absolute humidity (g/m³), air temperature, dew-point temperature and surface temperature (°C). This Metric-only measuring instrument comes complete with an external sensor probe for taking the surface temperature of different materials. - This device is used extensively in the construction industry to evaluate building materials and working conditions. It is also used in the food industry to ensure product quality and freshness. In addition, heating, ventilation and air conditioning (HVAC) technicians trust this meter to perform HVAC system performance audits. - The humidity detector is calibrated by the manufacturer. An optional ISO calibration certificate issued by an accredited calibration laboratory can be ordered. Please see the accessories tab for details.
