Temperature and Humidity Test Chamber SH-CTH-150SCR

Technical Specifications

• Temperature Range: Below room temperature, -45°C to 120°C (Lower temperature limit: -25°C)
• Humidity Range:
• 30% to 98% at temperatures from 20°C to 80°C
• 25% to 90% at temperatures from 80°C to 85°C
• 20% to 80% at temperatures from 85°C to 90°C
• Temperature Accuracy and Stability: ±0.1°C
• Temperature Uniformity: ±0.5°C
• Humidity Accuracy and Stability: ±1.5%
• Humidity Uniformity: ±2%
• Temperature & Humidity Controller: Touchscreen controller
• Temperature Sensor: Pt-100Ω
• Humidity Sensor: Electronic sensor
• Chamber Capacity: 150 liters
• Internal Dimensions (D × W × H): 500 × 500 × 600 mm
• External Dimensions (D × W × H): 950 × 995 × 1595 mm
• Weight: 210 kg
• Inner Chamber: Stainless steel
• Outer Body: Powder-coated steel plate
• Heating Power: 2.0 kW
• Humidity Power: 2.0 kW
• Lighting: LED light inside
• Observation Window: Glass with heating
• Water Reservoir: Stainless steel, with a heat-resistant coating
• Sample Shelf: Stainless steel wire, size 470 × 475 × 8 mm
• Max Number of Shelves: 17 shelves
• Power Supply: 230V, 50-60Hz, Single Phase
