LV SPRING VISCOMETER

LV SPRING VISCOMETER

LV SPRING VISCOMETER
Model: LV SPRING
Our new range of viscometers combines precision, ease of use and connectivity to meet the requirements of the most demanding laboratories and industrial environments.

Ứng dụng:

LV SPRING VISCOMETER
Model: LV SPRING
+Technology to Spring.
+Electronic bubble level.
+Programming and memorization of methods.
+Direct measurement with delay.
+User mode and protected mode.
+Storage and data transfer via USB.
+Display of the torque gauge.
+Printer connection.
+Compatible RheoTex software.
+Display of viscosity limits according to mobile and speed.
+Piloting in speed or gradient.
+Control of temperature controls.
+Multi-interval method.
+LIMS function.
+Function QC limits.
+Support with adjustable feet.
+Method wizard.
+Direct control of temperature unit.

Specifications
Type of instrument :
Rotating viscometer with spring and 7' touchscreen
Rotation speeds :
Unlimited speed between 0.1 and 250 r/min
Torque range :
0.06737 mNm
Temperature :
The LV SPRING has a PT100 sensor which indicates temperatures between -50 °C to + 300 °C.
Accuracy :
+/- 1 % of the full scale
Repeatability :
+/- 0,2 %
Display :
Viscosity ( cP/ Poises or mPa.s/ Pa.s) Speed- Shear gradient - Torque (%- mNm)- Stress- Time- Temperature- Electronic bubble level
Compatible accessories :
HELIPRO SPRING
Display for spindles
Protects touch screen
Verification oils
SMALL VOLUME KIT SPRING
THERMOCELL PACKAGE SPRING
Rheotex software
Security and confidentiality :
An «operator» function allows you to enter a username for you
instrument. This user must then be identified using a 4-digit code.
There is also a protected mode that locks your measurement
conditions.
Languages :
French/English/Russian/Spanish/Turkish/German/Italian/Korean/Portuguese/Ukrainian
Compatible measuring systems :
MS LV Spring, MS RV Spring, MS SV Spring, MS ULA Spring.
Compatible temperature control :
EVA LR, EVA MS DIN, RT-1 PLUS. *only with adaptation kit (Ref. SP01KIT).
Supply voltage :
90-240 VAC 50/60 Hz
PC connections :
RS232 and Ethernet USB port
Printer connection :
USB HOST Port- Compatible PCL/5
Dimensions and weight :
Head: D115 x H243 x W138 mm
Support: L340 x W305 x H70 mm
Stainless steel rod: Length 500 mm
Weight: 6.1 Kg
