Máy dò kim loại CQ-818

Máy dò kim loại
Model : CQ-818
Hãng Sản Xuất: Chao Qiang - Trung Quốc
Thông số kỹ thuật:
- Detection tunnel width (mm) : 400 mm ( Or customized )
- Un-load belt machine detection sensitivity : 100mm
+ Fe(Φmm) : ≥0.7mm
+ Non-Fe (Φmm): ≥1.3mm
+ 304 SUS(Φmm): ≥1.5
- Un-load belt machine detection sensitivity : 120mm
+ Fe(Φmm) : ≥0.8mm
+ Non-Fe (Φmm): ≥1.5mm
+ 304 SUS(Φmm): ≥2.0mm
- Un-load belt machine detection sensitivity : 150mm
+ Fe(Φmm) : ≥1.0mm
+ Non-Fe (Φmm): ≥1.8mm
+ 304 SUS(Φmm): ≥2.0mm
- Un-load belt machine detection sensitivity : 200mm
+ Fe(Φmm) : ≥1.5mm
+ Non-Fe (Φmm): ≥2.0mm
+ 304 SUS(Φmm): ≥2.5mm
- Un-load belt machine detection sensitivity : 250mm
+ Fe(Φmm) : ≥2.0mm
+ Non-Fe (Φmm): ≥2.5mm
+ 304 SUS(Φmm): ≥3.0mm
- Un-load belt machine detection sensitivity : 300mm
+ Fe(Φmm) : ≥2.5mm
+ Non-Fe (Φmm): ≥3.0mm
+ 304 SUS(Φmm): ≥3.5mm
- Un-load belt machine detection sensitivity : 350mm
+ Fe(Φmm) : ≥3.0mm
+ Non-Fe (Φmm): ≥3.8mm
+ 304 SUS(Φmm): ≥4.5mm
- Un-load belt machine detection sensitivity : 400mm
+ Fe(Φmm) : ≥3.5mm
+ Non-Fe (Φmm): ≥4.5mm
+ 304 SUS(Φmm): ≥5.0mm
Alarm method: Automatic shutdown, sound and light alarm. Or add rejector (Pusher ,Flap, Air,Belt drop)
