Coulometric Sensor Method Oxygen Permeability Analyzer Y310L

Coulometric Sensor Method Oxygen Permeability Analyzer Y310L

Coulometric Sensor Method Oxygen Permeability Analyzer
Model: Y310L
Brand:GBPI - China
Introduction
This product is designed and manufactured based on the coulometric sensor method and conforms to GB/T 19789、ASTM D3985.This instrument can be used to measure the oxygen transmission rate of barrier materials with high and medium barrier properties with high accuracy and high efficiency.Y310Lis applicable to the determination of oxygen permeability of plastic films, sheeting, paper, and other packaging materials used in food, pharmaceutical, medical apparatus, consumer products, photovoltaic and electronic industries, etc

Ứng dụng:

Coulometric Sensor Method Oxygen Permeability Analyzer
Model: Y310L
Brand:GBPI - China
- Standards:  ASTM D3985,ASTM F2622,ASTM F1927,ASTM F1307,ISO 15105-2,DIN 53380-3,JIS K7126-B
Specification:
 - Parameters Testing Range: 0.05 - 1000 cm³/(m²·24h·0.1MPa)
- Oxygen Measurement Resolution:  0.0001 cm³/(m²·24h·0.1MPa)
- Temperature Control Range: 15 - 45℃
- Temperature Control Precision: ±0.2℃
- Humidity Control Range:  0%RH, 5 - 90%RH, 100%RH
- Humidity Control Precision: ±2%RH
- Permeation Area:  50.24 cm² (Customizable adapters available, minimum down to 0.785 cm²)
- Specimen Size: Φ100 mm
- Specimen Thickness: ≤3 mm
- Number of Specimen: 3 pieces
- Carrier Gas Pressure: ≥0.1 MPa
- Carrier Gas Flow Rat: 5 - 100 mL/min
- Overall Dimensions: 700 mm×655 mm×535 mm
- Weight: 60 kg
- Power :750 W
- Power Supply :AC 220 V, 50 Hz
Features:
1) High precision oxygen sensor:
High-precision imported oxygen sensor with high sensitivity, ultra-high stability and ultra-low failure rate, with a resolution of 0.0001 cm³/(m²·24h·0.1MPa).
2) The test data is accurate and reliable :
Precise control of test temperature and humidity. Equipped with high-precision temperature and humidity sensors, the temperature and humidity of the test chamber are stable, and the temperature control is precise The temperature can reach 0.2℃, and the humidity can be accurate to±2%RH. Automatic test mode, real-time monitoring of temperature, humidity, gas flow valuesand curves during the test process, high test repeatability.
3) Independent three-chamber design, high test efficiency:
 The instrument is equipped with 3 chambers, each of which has a standard area of50.24cm2, which can meet the standard test requirements of three parallel samples, and the test efficiency is high.
It supports simultaneous testing of three identical or different samples, and the test data are independent of each other.
The measurement range is 0.05~1000 cm³/(m²·24 h·0.1 MPa), and the measuring range is wide, meeting the testing requirements of high, medium and low barrier materials. With the addition of adapter accessories, it can measure the oxygen transmission rate of bottles, bags, bowls and other containers.
