FTM-50 Computerized Structure Analyzer

Volumetric Melt Flot Flow Indexer model MFI-500-AUTO - Gravimetric and volumetric method. - Computerized by Melt Flow Index Software (Mini PC included in the supply). - The Testing Software allows testing and determines the flow rate. - Automatic sample cutting. - PID temperature controller (holding ± 0.1ºC). - Programmer of time and number of cutting cycles. - Equipment prepared to work with corrosive materials such as PVC. - The kit includes all working and cleaning tools, piston and standard nozzle. - Standard temperature range up to +325 ºC (*) with resolution of ± 0.1ºC. - Digital stopwatch with a range of up to 9999 seconds. - 7 Chromed and polished weights included in the standard supply: 1.2 Kg – 2.16 Kg – 3.8 Kg – – 5 Kg – 5 Kg – 6.6 and 10 Kg (The weight of 21.6 kg is achieved by combining the weights of 5kg, 6.6kg and 10kg). - Motorized automatic weight loader. - RS-232 output interface with converter to USB. - To calculate the Melt Index in the MFI-500/AP model using the Gravimetric method, it is necessary to weigh the extruded material with a - resolution of 0.001 g, therefore we recommend using a precision balance. - CE marked. Standards ASTM D1238, DIN 1133, EN 1133, ISO 1133, UNE 1133.

VICAT-HDT Softening Test Apparatus - Standards: ASTM D 648, ASTM D 1525, ISO 75-2, ISO 306, DIN 53460, DIN 53461, UNI EN ISO 75-2, UNI EN ISO 306. - Applications: Automobile panels. Tubes and plastic pipes. Automotive dashboards. - Description Laboratory test equipment for the determination of the softening point VICAT and the bending temperature HDT in thermoplastic materials.

- Description: Basic plastometer for the determination of the melt index in thermoplastic materials by the gravimetric method. - Standards: ASTM D1238, DIN 1133, EN 1133, ISO 1133, UNE 1133.

Rebound Resilience Tester RB-10D - The test apparatus allows to determine the rebound percentage of the hammer measured over its height of fall. The test piece used is circular with a diameter of 44.6 mm and a thickness of 6 mm. Failing this, a round or square piece of rubber can be used, measuring approximately • Power: 0.5 Joules – 5 Kg. cm • Bounce rate: 0-100% • Angle of fall: 90º - Standards ISO 4662 – DIN 53512 – ASTM D 1054

Electromechanical Material Testing Machine MTE-1L (1 kN)

Abrasion Tester AT-50 - Description Laboratory equipment to determine the resistance to wear by abrasion of standardized samples of Rubber, Plastics, Leather... - Standards: ASTM D 5963 – ISO 4649
